Model：MPAR-060180S48

Frequency Range: 6-18GHz
Output Power: 70W Typ./50W Min.
Gain: 49dB Typ.
Gain Flatness: ±2.5dB Max.
2nd/3nd Harmonics: -12/-12dBc Max.
Power Consumption: 1000W Max.
Outline Drawing: 482.6 x 221.5 x 480mm (5U)

Model：MPAR-060180S50

Frequency Range：6-18GHz
Output Power：100W Typ./80W Min.
Gain：50dB Typ.
Gain Flatness：±2.5dB Max.
2nd/3nd Harmonics：-12/-12dBc Max.
Power Consumption：1900W Max.
Outline Drawing：482.6x221.5x480mm (5U)

Model：MPAR-265400S43

Frequency Range: 26.5-40GHz
Output Power: 20W Typ./16W Min.
P1dB: 10W Typ. /5W Min.
Gain: 43dB Typ.
Gain Flatness: ±4.5dB Max.
Power Consumption: 550W Max.
Outline Drawing: 482.6 x 177 x 503mm (4U)
