Model：MPAC-017060-50E

Frequency：2~6GHz
Attenuation Range：50dB @0.1dB Step
Attenuation Accuracy：±0.1dB Typ.，±0.2dB Max.
Phase Shift Range：360º@1º Step
Phase Accuracy：±1º Typ, ±2º Max,.

Model：MPAC-180400-50E

Frequency：18~40GHz
Attenuation Range：50dB @0.1dB Step
Attenuation Accuracy：±0.1dB Typ., ±0.2dB Max.
Phase Shift Range：360º@1º Step
Phase Accuracy：±1º Typ, ±2.5º Max,

Model：MPAC-240400-50E

Frequency：24~40GHz
Attenuation Range：50dB @0.1dB Step
Attenuation Accuracy：±0.2dB Typ.，±0.4dB Max.
Phase Shift Range：360º@1º Step
Phase Accuracy：±1º Typ, ±2º Max
