90GHz High Speed Multi-Coax Cable Assemblies
Release time：2026-01-19 Author：MIcable Browse times：155
MIcable HSM90 series high-speed multi-coax cable assemblies are specially designed for superior signal measurement, differential signal measurement, SERDES development, and automated testing in super high frequency environments up to 90GHz.
The HSM90 connectors utilize a solderless spring-load contact design, ensuring the multi-channel connection reliability and ease of installation & replacement.
There're single-row and dual-row alignments to choose for your application, the standard contact pitch is 3.0mm for both single row alignment and double row's, which minimizes PCB space usage by 70% or above, and tighter pitch within 2.5mm and 3.0mm is available for customization.
The HSM90 assemblies offer outstanding electrical performance in low return loss, low insertion loss and skew match accuracy, the return loss is less than -14dB@90GHz, and the skew match accuracy is less than +/-0.5ps typically.
The HSM90 is a best choice for your various super high frequency applications.
The HSM90 connectors utilize a solderless spring-load contact design, ensuring the multi-channel connection reliability and ease of installation & replacement.
There're single-row and dual-row alignments to choose for your application, the standard contact pitch is 3.0mm for both single row alignment and double row's, which minimizes PCB space usage by 70% or above, and tighter pitch within 2.5mm and 3.0mm is available for customization.
The HSM90 assemblies offer outstanding electrical performance in low return loss, low insertion loss and skew match accuracy, the return loss is less than -14dB@90GHz, and the skew match accuracy is less than +/-0.5ps typically.
The HSM90 is a best choice for your various super high frequency applications.
